perovskite atlas Structures, modes and phase transitions · Josu M. Igartua · UPV/EHU

Figure 8.8 · Thesis 4 · Orayech 2015

Figure 8.8 · Thesis 4 · Orayech 2015

status thesis-only · visibility public · id plt:thesis-04.8.8

Open in its own tab ↗
Temperature evolution of the lattice parameters of $\mathrm{Sr}_{2} \mathrm{MSbO}_{6}$. The cell parameters of the trigonal phase are shown in the hexagonal notation. The monoclinic and hexagonal parameters have been scaled to be comparable with the edge of the centered cubic. The $\mathrm{Sr}_{2} \mathrm{MSbO}_{6}$ materials undergo two phase transitions: a first-order one, discontinuous, transforming the cell from a monoclinic to a trigonal and a second one of the second-order from a triginal to a cubic cell. The phase-transition sequence is the following: $P 2_{1} / n \rightarrow R \overline{3} \rightarrow F m \overline{3} m$.

Temperature evolution of the lattice parameters of \mathrm{Sr}_{2} \mathrm{MSbO}_{6}. The cell parameters of the trigonal phase are shown in the hexagonal notation. The monoclinic and hexagonal parameters have been scaled to be comparable with the edge of the centered cubic. The \mathrm{Sr}_{2} \mathrm{MSbO}_{6} materials undergo two phase transitions: a first-order one, discontinuous, transforming the cell from a monoclinic to a trigonal and a second one of the second-order from a triginal to a cubic cell. The phase-transition sequence is the following: P 2_{1} / n \rightarrow R \overline{3} \rightarrow F m \overline{3} m.

Document
Thesis 4 · Orayech 2015
Figure
8.8
Kind
cell-vs-t
Rights
own
Reproduce
not-needed

auto-cropped from the OCR Markdown crop box (stage B); materials and kind to be reviewed in Phase 1

Evidence
